Thermocouple Wires and Instrument Cables
S.No. Size Type of Cable
01. 3/22 PVC/PVC
02. 3/22 PVC/PVC Asbestos
03. 3/22 PVC/PVC/ASB/GI
04. 3/22 PVC/PVC/GI
05. 3/22 PVC/ASB
06. 3/22 FG/FG
07. 3/22 FG/FG/SS
08. 3/22 FG/FG/ASB
09. 3/22 ASB/ASB
10. 3/22 ASB/ASB
11. 1/26 Teflon/Teflon
12. 7/36 Teflon/Teflon/SS
13. 7/36 Teflon/Teflon/FG
14. 7/36 Teflon/Teflon/FG/SS
15. 7/36 Teflon/Teflon/SPC/Teflon
16. 40/36 Neoprene Rubber


programmable counter, digital conductivity controller
Request A Quote

Following special cables are also available

  1. Single pair or Multi pair armoured cables
  2. Instruments signal transmission cables
  3. Screened cables
  4. Computer cables


conductivity indicator, conductivity transmitter
Request A Quote

Thermocouple & RTD Assemblies

Available in sheath size of 3, 4.5, 5, 6, 8, 10, 12.5, 19, 22 and 25 mm OD pipe Sheath material : SS 304, 310, 316 or 446 Ceramic Thermocouples available in 610 and 710 Die cast aluminium heads with brass terminals Wire size of 16, 14, 12 or 10 SWG All types and sizes of process fittings available in MS, SS or Brass Thermowells fabricated as per the coustomer's drawings and specifications. Flame proof thermocouples certified by D.G.M.S. L - Shaped thermocouples for Salt Bath Special thermocouples for plastic and rubber extrusion e.g bayonet, screw, bolt and washer types. .
